Product overview
The BioScape 5-in-1 Submersible System is an all-in-one pump, filter, UV clarifier and fountain for garden ponds, pre-formed water features and small fish ponds. Everything sits in one unit on the pond floor, with no external plumbing, hoses or pressure canister.
The five functions
-
Pump: Low-voltage 24 V DC pump moving up to 2,000 L/h to keep water oxygenated and moving.
-
Mechanical filtration: A coarse sponge catches large debris and a fine sponge polishes out smaller particles.
-
Biological filtration: Ceramic rings give beneficial bacteria plenty of surface to grow on.
-
UV clarifier: Built-in 8 W UV-C clears green water caused by free-floating algae and reduces bacterial blooms.
-
Fountain and light: Telescopic stem with interchangeable fountain heads, plus an LED ring that turns on automatically at dusk.
Key features
-
No external plumbing: Sits on the pond floor, so there's no risk of a failed hose draining the pond.
-
Low voltage: Runs on 24 V through a step-down transformer for safer outdoor use.
-
Day/night sensor: The LED ring switches on at night and off during the day.
-
Adjustable flow: Telescopic risers give fountain heights up to 1.3 m. A diverter valve runs a fountain and a small waterfall or spitter at the same time.
Water and system compatibility
-
Water: Freshwater ponds only.
-
Suits: Outdoor ornamental ponds, goldfish ponds and pre-formed pond basins up to 2,000 L.
Need to work out your tank's litreage? Use our volume calculator.
Specifications
-
Max flow: 2,000 L/h
-
Pond size: Up to 2,000 L
-
Total power: Approx. 35 W
-
UV-C lamp: 8 W
-
LED ring: 1 W, automatic light sensor
-
Power supply: 220–240 V AC to 24 V DC transformer
-
Cable length: 6 m, including transformer
-
Max fountain height: 1.3 m
-
Size: Approx. 31 × 24 × 15 cm (L × W × H)
What's included
- Submersible 2,000 L/h filter unit
- Built-in 8 W UV-C clarifier with quartz sleeve and lamp
- Coarse and fine filter foams
- Ceramic biological media
- 24 V DC outdoor transformer with 6 m cable
- Dusk-to-dawn LED light ring
- Telescopic fountain riser and diverter valve
- Fountain heads: bell, tiered spray and multi-jet
- Instructions
Installation
Always follow directions on product packaging.
